Overview
Vertical gear hobbing machine for cylindrical gears and related transmission parts.
This model is part of Changyi's Gear Processing Equipment lineup for buyers comparing Chinese CNC machine tools, technical parameters and export-ready quotation options. Applications
Applications
Used for hobbing spur gears, helical gears and other gear workpieces in general machinery production.
Technical Parameters
Technical Parameters
All equipment can be customized; inquiries and discussions are welcome.
Model NO.
Y3180H
Type
Gear Hobbing Machine
CNC or Not
Normal
Voltage
380V
Certification
IS09001
Max. Workpiece Diameter
500mm
Max. Workpiece Module
8 mm
Max. Tooth Width
250mm
Max. Installation Diameter of Hob
160mm
Max. Installation Length of Hob
160mm
Worktable Diameter
510mm
Taper of Spindle Bore
Mt5
380~850 / Diameter of Worktable Center Hole
80
Trademark
NORTH CRAFTSMAN
Origin
China
HS Code
8461409000
Production Capacity
100 Sets/Year
Product Videos
Y3180H video 1Media
Inquiry
Send an inquiry: Y3180H
Please include product model, workpiece information, destination country and required delivery schedule.
